Electro Harmonix Nano Clone Analog Chorus Pedal

The Electro-Harmonix Nano Clone delivers rich, shimmering analogue chorus in a compact, affordable and refreshingly straightforward pedal. Inspired by the celebrated Electro-Harmonix Small Clone, it creates a spacious doubling effect that can add subtle movement, fluid modulation or fast rotary-style animation to your instrument.

A single Rate control adjusts the speed of the chorus, making the Nano Clone exceptionally easy to operate. Slower settings add gentle width and depth to clean chords, while faster settings create a more obvious, pulsing modulation effect.

Its true analogue circuit, true-bypass switching and durable die-cast enclosure make the Nano Clone an excellent choice for guitarists, bassists and keyboard players seeking classic chorus without complicated controls or a large pedalboard footprint.

Quick Product Summary

The Electro-Harmonix Nano Clone is a compact analogue chorus pedal designed to create lush, shimmering doubling effects.

Its single Rate control covers slow, spacious modulation through to fast and animated chorus sounds. The streamlined layout makes it particularly suitable for players who want a dependable chorus effect without menus, secondary controls or extensive adjustment.

At A Glance

Feature	Details
Brand	Electro-Harmonix
Model	Nano Clone
Product Type	Analog chorus pedal
Circuit	Analogue
Control	Rate
Bypass	True bypass
Audio Format	Mono
Input Impedance	300kΩ
Output Impedance	600Ω
Power	9V battery or compatible external adapter
Current Draw	12mA
Dimensions	4.5 × 2.75 × 2.1 inches
Enclosure	Compact die-cast chassis
Year Introduced	2006
Main Appeal	Simple, affordable analogue chorus in a compact format
Best For	Rock, indie, pop, alternative, funk, ambient and clean guitar
Suitable Instruments	Guitar, bass, keyboards and compatible electronic instruments
Condition	Brand New

Why Choose the Electro-Harmonix Nano Clone?

Genuine Analogue Chorus

The Nano Clone uses an analogue circuit to create its modulation effect.

It slightly alters the pitch of the incoming signal before combining it with the original unaffected sound. The interaction between these signals creates the familiar sense of movement, width and doubling associated with chorus.

Its analogue character works especially well with:

• Clean electric guitar

• Light overdrive

• Arpeggiated chords

• Sustained notes

• Bass guitar

• Electric piano

• Synthesisers

• Ambient effects chains

Lush Shimmering Doubling

At moderate settings, the Nano Clone adds width and movement without completely transforming the original instrument tone.

This can make a single guitar part feel broader and more dimensional, helping it occupy more space within a live or recorded arrangement.

The effect is particularly useful for:

• Clean rhythm guitar

• Open chord voicings

• Arpeggios

• Melodic lead lines

• Eighties-inspired clean sounds

• Alternative-rock textures

• Ambient layers

Simple Rate Control

The single Rate knob adjusts the speed of the chorus modulation.

Turning the control anticlockwise produces a slower and more gradual sweep. This creates a spacious sound that can add depth without becoming overly obvious.

Turning the Rate control clockwise increases the modulation speed, producing a faster and more animated effect.

This streamlined design makes the Nano Clone easy to adjust during rehearsals, recording sessions and live performances.

Slow, Spacious Modulation

Lower Rate settings add gentle pitch movement behind the original signal.

These settings are particularly effective for:

• Slow chord progressions

• Clean arpeggios

• Ballads

• Ambient guitar

• Sustained keyboard sounds

• Subtle studio layering

The effect can add dimension while allowing the original playing dynamics and note attack to remain clear.

Fast, Animated Chorus

Higher Rate settings produce a more obvious pulse and faster modulation.

This can create:

• Vibrant indie-guitar textures

• Animated funk sounds

• Psychedelic modulation

• Rotary-inspired movement

• Experimental effects

• Fast, watery chorus

The wide Rate range allows the pedal to move beyond subtle doubling into more distinctive modulation sounds.

Works with Clean and Driven Tones

The Nano Clone can be used with both clean and overdriven sounds.

With a clean amplifier, it produces a clear and spacious doubling effect. When combined with overdrive or distortion, the modulation becomes thicker and more integrated into the harmonic content of the driven tone.

The final result will also depend on whether the chorus is positioned before or after the gain pedals.

Compact Pedalboard Format

The Nano Clone places its analogue chorus circuit inside a compact Electro-Harmonix enclosure.

Its narrow footprint leaves valuable room for additional effects such as:

• Tuners

• Overdrives

• Fuzz pedals

• Phasers

• Delays

• Reverbs

• Loop switchers

The durable die-cast chassis is designed for regular pedalboard, rehearsal and live use.

True-Bypass Switching

The Nano Clone uses true-bypass switching.

When the pedal is disengaged, the active chorus circuit is removed from the signal path. A status LED clearly indicates when the effect is switched on.

Low Power Consumption

With a current draw of 12mA, the Nano Clone places very little demand on a compatible pedalboard power supply.

It can also operate from a standard 9V battery, making it suitable for smaller setups without a dedicated mains-powered pedalboard.

Why Choose an Analogue Chorus Pedal?

A chorus pedal creates the impression of two or more instruments playing together by blending the original signal with a slightly delayed and modulated copy.

This produces subtle variations in pitch and timing, adding width and movement to the sound.

Chorus can be used to:

• Make clean guitar sound wider

• Add movement to sustained chords

• Create shimmering arpeggios

• Thicken lead guitar

• Animate bass lines

• Add depth to keyboards

• Produce eighties-inspired guitar sounds

• Create ambient textures

• Add contrast between song sections

• Enrich recorded instrument layers

An analogue chorus such as the Nano Clone offers this modulation through a simple physical interface without digital menus or preset programming.

Who Is the Electro-Harmonix Nano Clone For?

Guitarists Buying Their First Chorus Pedal

The single-control design makes the Nano Clone an accessible introduction to chorus effects.

Players with Compact Pedalboards

Its Nano-sized enclosure provides analogue modulation without taking up the space required by larger chorus pedals.

Indie and Alternative Guitarists

Shimmering clean sounds and more obvious fast modulation work naturally within indie, alternative and post-punk arrangements.

Pop and Rock Musicians

The Nano Clone can add width to clean verses, melodic lead lines and contrasting song sections.

Ambient Players

Slower settings combine effectively with delay and reverb to create broad, evolving textures.

Funk Guitarists

Faster settings can add movement to muted chord patterns and percussive rhythm playing.

Bassists

The Nano Clone can add width and movement to bass lines, sustained notes and melodic passages.

Keyboard and Synthesiser Players

Compatible mono keyboard and synthesiser signals can be processed to create richer, wider and more animated sounds.

Recording Musicians

Its straightforward control makes it easy to create repeatable chorus sounds while tracking or re-amping.

What’s Included?

• Electro-Harmonix Nano Clone Analog Chorus pedal

• 9V battery

External power adapter not included.

Fair Deal Quality Control Assessment

Every effects pedal supplied by Fair Deal Music is checked by our experienced team before dispatch.

Our assessment includes:

• Enclosure and finish inspection

• Input socket test

• Output socket test

• Full Rate-control range assessment

• Slow and fast modulation check

• Footswitch operation

• Status LED inspection

• True-bypass test

• Battery operation

• External power input check

• Final presentation and packing inspection

Technical Specifications

General

Specification	Details
Effect Type	Chorus
Circuit Type	Analogue
Audio Format	Mono
Bypass Type	True bypass
Control	Rate
Enclosure	Compact die-cast chassis
Year Released	2006
Dimensions	4.5 × 2.75 × 2.1 inches
UPC	683274050058

Controls

Control	Function
Rate	Adjusts the speed of the chorus modulation
Footswitch	Selects effect or true-bypass operation
Status LED	Illuminates when the chorus effect is active

Connections

Connection	Details
Input	¼-inch mono audio input
Input Impedance	300kΩ
AMP Output	¼-inch mono audio output
Output Impedance	600Ω
Power Input	Centre-negative DC barrel connection

Power Requirements

The Electro-Harmonix Nano Clone can operate from a 9V battery or a compatible regulated external power supply.

Specification	Details
Operating Voltage	9V DC
Current Draw	12mA
Polarity	Centre-negative
Battery Type	9V
Recommended Adapter	Electro-Harmonix 9.6V DC 200mA

When using battery power, inserting a cable into the Input socket activates the pedal. Disconnect the input cable when the Nano Clone is not being used to preserve battery life.

Always use a regulated external power supply with the correct voltage and polarity.

Where Should the Nano Clone Be Placed?

There is no single correct pedal order, but the following positions provide useful starting points.

After Overdrive and Distortion

This conventional placement applies the chorus effect to the complete driven sound.

It normally produces a clear and pronounced modulation that works well for rock, pop and alternative guitar.

Before Overdrive and Distortion

Placing the Nano Clone before gain allows the overdrive or distortion to process the modulated signal.

This can create a more compressed and integrated chorus effect.

Before Delay and Reverb

Placing chorus before delay and reverb allows the later effects to repeat and expand the modulated sound.

This is an excellent starting point for ambient, indie and clean guitar textures.

In an Amplifier Effects Loop

Using the Nano Clone in an effects loop can keep the chorus clear when the amplifier’s preamp is providing distortion.

The amplifier must offer a compatible instrument-level or suitably controlled effects loop.

Electro-Harmonix Nano Clone Compared with Other Chorus Pedals

Nano Clone vs Electro-Harmonix Small Clone

The Small Clone is the classic Electro-Harmonix chorus design that inspired the Nano Clone.

The Small Clone offers a Rate control and additional Depth switching, providing greater control over the intensity of the modulation.

The Nano Clone focuses on affordability, compact dimensions and straightforward single-control operation.

Choose the Nano Clone for maximum simplicity and pedalboard efficiency. Choose the Small Clone when additional depth control is required.

Nano Clone vs Electro-Harmonix Neo Clone

The Neo Clone uses an analogue chorus circuit with a Rate control and a two-position Depth switch.

The Nano Clone is the simpler and more affordable option, providing direct control over modulation speed without additional switching.

Choose the Nano Clone for one-knob operation. Choose the Neo Clone for greater control over chorus depth.

Nano Clone vs Digital Chorus Pedals

Digital chorus pedals may offer stereo connectivity, presets, multiple modulation types and detailed parameter control.

The Nano Clone focuses on a dedicated analogue chorus sound with an immediate physical interface.

Choose the Nano Clone for simplicity and analogue character. Choose a digital modulation pedal when presets and multiple effect types are required.

Nano Clone vs a Flanger

A flanger generally creates a sharper, more metallic comb-filter effect with pronounced sweeping movement.

The Nano Clone produces a smoother doubling effect that is often better suited to widening clean guitar and adding gentle movement.

Nano Clone vs a Phaser

A phaser creates moving peaks and notches across the frequency spectrum, producing a swirling filter-like effect.

The Nano Clone uses pitch and timing modulation to create a wider, doubled sound.

Choose chorus for width and shimmer. Choose a phaser for a more obvious sweeping effect.

Frequently Asked Questions

Is the Electro-Harmonix Nano Clone analogue?

Yes. It uses a true analogue chorus circuit.

What does the Rate control do?

The Rate knob adjusts the speed of the chorus modulation.

Lower settings create a slow and spacious effect, while higher settings produce faster and more animated movement.

Does the Nano Clone have a Depth control?

No. The pedal uses a single Rate control to keep operation simple.

Players requiring adjustable depth may prefer the Electro-Harmonix Neo Clone or Small Clone.

Can it produce subtle chorus?

Yes. Lower Rate settings provide gentle movement that can add depth without dominating the original sound.

Can it create fast modulation?

Yes. Turning Rate clockwise produces a quicker and more obvious chorus effect.

Is it suitable for bass guitar?

Yes. The Nano Clone can add width and movement to bass lines and sustained notes.

Can it be used with keyboards?

Yes. Compatible mono keyboard and synthesiser signals can be processed through the pedal.

Is the Nano Clone stereo?

No. It has one mono input and one mono output.

Does it use true bypass?

Yes. The active chorus circuit is removed from the signal path when the pedal is disengaged.

Can it run from a battery?

Yes. A 9V battery is supplied.

How much current does it require?

The Nano Clone draws 12mA at 9V DC.

Is it the same as the Small Clone?

No. The Nano Clone draws inspiration from the Small Clone but uses a simpler single-control design in a compact, budget-conscious format.

Fair Deal Music Verdict

★★★★★ 5/5

The Electro-Harmonix Nano Clone is an excellent choice for players who want warm analogue chorus without unnecessary controls or a large pedalboard footprint.

Its single Rate knob makes it exceptionally easy to use, covering gentle shimmering movement, spacious clean sounds and faster animated modulation. True bypass, low power consumption and a rugged compact enclosure add dependable modern practicality.

For guitarists, bassists and keyboard players seeking an affordable route into genuine Electro-Harmonix analogue chorus, the Nano Clone offers distinctive sound and outstanding simplicity.
