Studiomaster Club XS 10+ Mixer
Studiomaster Club XS10+ 10-Channel Analogue Mixer with Bluetooth, USB/SD Recording & DSP Effects
The Studiomaster Club XS10+ is a 10-channel analogue mixing console designed for live performers, small bands, rehearsal rooms, schools, houses of worship, DJs, presenters, home recording and compact PA setups. Sitting between the Club XS8+ and Club XS12+, it gives you a strong balance of microphone inputs, portability and practical live sound features.
With 10 inputs, 6 mic channels and 2 stereo channels, the Club XS10+ is ideal for mixing vocals, acoustic instruments, keyboards, backing tracks, laptops, phones and media players from one straightforward desk. It also includes Bluetooth playback, USB/SD media playback and recording, 16 built-in DSP effects and a DSP on/off footswitch socket, making it a flexible option for users who want an analogue mixer with modern convenience features.
The mic channels include useful live-sound tools such as 3-band EQ, adjustable compression, high-pass filtering and mute switching, while the stereo channels include 2-band EQ for shaping keyboards, media players and other stereo sources. With balanced XLR main outputs, auxiliary outputs, control room outputs, headphone monitoring and phono record/playback connections, the Club XS10+ is well suited to small-to-medium live, rehearsal and recording environments.
Why Choose The Studiomaster Club XS10+?
10-Channel Mixing For Flexible Setups
The Club XS10+ gives you more input capacity than the XS8+ while staying more compact than the XS12+ and XS16+. With 6 mic channels and 2 stereo channels, it is a practical choice for solo performers, duos, small bands, presenters, schools and venues that need several microphones plus stereo playback sources.
Built-In Bluetooth Playback
Bluetooth playback makes it easy to stream audio wirelessly from a compatible phone, tablet or laptop. This is ideal for backing tracks, interval music, rehearsal playback, DJ playlists, presentation audio and background music during events.
USB/SD Playback & Recording
The USB/SD media section allows MP3 playback and direct recording to USB drive or SD card. This gives you a simple way to capture rehearsals, record basic live performances or play music without needing a separate computer or media player. Published specifications list USB/SD recording as 128kbps mono.
16 Built-In DSP Effects
The Club XS10+ includes 16 DSP effects, including reverb, delay and stereo effects. This helps vocals, instruments and spoken-word audio sound more polished without needing an external effects processor. A dedicated DSP on/off footswitch socket also makes effects control easier during live performance.
EQ, Compression & High-Pass Filtering
Each mic channel includes 3-band EQ, adjustable compressor control and high-pass filtering. This helps shape vocals, control dynamics and reduce unwanted low-frequency rumble during live use. Stereo channels include 2-band EQ for simple tone control over keyboards, playback devices and other stereo sources.
Mute Control On Input Channels
Mute switches make live operation easier, allowing you to silence unused channels, control playback sources, manage performers and keep your mix cleaner during rehearsals, events and performances.
Balanced Outputs & Useful Routing
Balanced XLR main outputs give you a proper connection to powered speakers, PA systems or recording equipment. Auxiliary outputs, control room outputs, headphone monitoring and phono record/playback connections add useful flexibility for small live sound, rehearsal and recording setups.
Why Choose A 10-Channel Analogue Mixer?
A 10-channel analogue mixer is a strong choice when a compact 6 or 8-channel desk does not give you quite enough room, but a 12 or 16-channel mixer feels larger than necessary. It gives you space for multiple vocal microphones, instruments, stereo sources and playback devices while keeping the workflow simple and hands-on.
For performers, this means you can run vocals, acoustic guitar, keyboard and backing tracks from one mixer. For schools, presenters and venues, it gives flexible microphone and media control. For rehearsal rooms and home recording, it provides a practical centrepiece for managing multiple sources without constantly repatching equipment.
The Studiomaster Club XS10+ is especially useful because it combines traditional analogue control with Bluetooth playback, USB/SD recording and onboard DSP effects, making it a versatile mixer for modern live, rehearsal and event use.
Who Is It For?
Beginners
A good choice for users who need more flexibility than a very small mixer but still want a clear, approachable analogue layout. It is straightforward to use while offering enough features to grow into.
Intermediate Users
Ideal for solo performers, duos, small bands, rehearsal rooms, schools, presenters, DJs, streamers and compact PA setups that need multiple mic inputs, Bluetooth playback and built-in effects.
Advanced & Professional Users
Useful as a portable live sound mixer, rehearsal-room desk, keyboard submixer, small installation mixer, backup desk, playback mixer or compact event production tool.
Technical Specifications
| Specification | Details |
|---|---|
| Product Type | Analogue Mixing Console |
| Model | Studiomaster Club XS10+ |
| Inputs | 10 |
| Mic Channels | 6 |
| Stereo Channels | 2 |
| Mic Channel EQ | 3-band EQ |
| Stereo Channel EQ | 2-band EQ |
| Compression | Adjustable compressor control on mic channels |
| High-Pass Filter | 100Hz high-pass filter on mic channels |
| Mute Control | Mute switching on input channels |
| Auxiliaries | 2 auxiliary sends |
| DSP Effects | 16 built-in DSP effects |
| Footswitch Socket | DSP on/off footswitch socket |
| Bluetooth | Yes, Bluetooth playback |
| USB/SD Media | MP3 playback and recording |
| Recording | USB/SD recording, listed as 128kbps mono |
| Main Outputs | Balanced XLR main outputs |
| Additional Outputs | Aux outputs, control room outputs, headphone monitoring and phono record/playback connections |
| Phantom Power | +48V phantom power on mic channels |
| Mic Gain Range | 6dB to 50dB |
| Line Gain Range | 10dB to 34dB |
| EIN | -100dB |
| Frequency Response | 10Hz – 20kHz, +1/-3dB |
| THD Mic Channel | Less than 0.1% |
| Signal-to-Noise Ratio | 80dB |
| Output Levels | Max +26dB balanced / +20dB unbalanced |
| EQ Frequencies | Hi 12kHz, Mid 2.5kHz, Lo 45Hz, low cut 80Hz |
| Power Requirement | 100V–240V AC, 50/60Hz |
| Dimensions | 360mm x 80mm x 365mm |
| Weight | 5kg |
| Suitable For | Solo performers, duos, small bands, rehearsal rooms, schools, DJs, streaming, events and home recording |
Power Requirements
The Studiomaster Club XS10+ is mains powered and listed with universal 100V–240V AC, 50/60Hz compatibility, making it suitable for standard UK use with the correct power lead.
Why Buy From Fair Deal Music?
Fair Deal Music has been a family-run independent music retailer since 1987 and is Birmingham’s largest independent music store. We offer expert advice, secure online ordering, fast UK delivery and support from a team of musicians who understand live sound, rehearsal spaces, recording and performance equipment.
Our team can help you choose the right mixer for your setup, whether you are building a compact PA system, rehearsal room rig, school audio setup, venue sound system, streaming station or home recording environment. With thousands of excellent customer reviews and a large Birmingham showroom, Fair Deal Music gives you trusted service before and after your purchase.
FAQs
Is the Studiomaster Club XS10+ a digital mixer?
No. The Club XS10+ is an analogue mixer with built-in digital DSP effects, Bluetooth playback and USB/SD media features. It does not offer full digital mixer control or scene recall.
How many channels does the Studiomaster Club XS10+ have?
The Club XS10+ has 10 inputs, including 6 microphone channels and 2 stereo channels.
Does the Club XS10+ have Bluetooth?
Yes. The Studiomaster Club XS10+ includes Bluetooth playback for wireless audio streaming from compatible devices.
Does the Club XS10+ have built-in effects?
Yes. It includes 16 built-in DSP effects, including reverb, delay and stereo effects, plus a DSP on/off footswitch socket for live control.
Can the Club XS10+ record audio?
Yes. It supports recording to USB drive or SD card. Published specifications list recording as 128kbps mono.
Is the Studiomaster Club XS10+ suitable for live performance?
Yes. With 6 mic channels, 2 stereo channels, EQ, compression, aux routing, DSP effects and balanced outputs, it is well suited to solo performers, duos, small bands and compact PA systems.
Does the Club XS10+ have phantom power?
Yes. Published specifications list +48V phantom power on mic channels for compatible condenser microphones.
What is the difference between the Club XS8+ and Club XS10+?
The Club XS8+ has 8 inputs and 4 mic channels, while the Club XS10+ gives you 10 inputs and 6 mic channels. Choose the XS10+ if you need more microphone capacity for vocals, instruments or small band setups.
What is the difference between the Club XS10+ and Club XS12+?
The Club XS10+ is more compact and easier to manage, while the Club XS12+ offers more input capacity with 12 inputs and 8 mic channels. Choose the XS10+ for smaller-to-medium setups and the XS12+ if you need extra microphone channels.
Is the Club XS10+ portable?
Yes. Published specifications list dimensions of 360mm x 80mm x 365mm and a weight of 5kg, making it portable for a 10-channel analogue mixer.
